Add SSL Cert to Nginx

· 3 min read
Ayyaz Akhtar
Engineer @ Disney

cover

This tutorial will go over how to add a Namecheap ssl certification to your nginx web server.

Prerequisites​

Purchased Namecheap Domain name + SSL
Server is remote accessible with proper software installed

Create SSL Certification​

Path​

The path the to certs will need to be referenced later in the nginx config.

This example will be using /root as the path.

# Key
/root/example.com.key

# CSR
/root/example.com.key.com.csr

# SSL Bundle
/root/example.com.key_com.crt
/root/intermediate.crt

# SSL Cert
/root/example.com.key.com.chained.crt

Generate CSR​

A certificate signing request (CSR) generated by openssl will be used to initialize the process.

  • newKey rsa:2048
    • Generates new private key and cert
    • Using rsa:2048
  • nodes
    • Does not encrypt private key
  • keyout /$PATH/example.com.key
  • out /$PATH/example.com.key.com.csr
openssl req \
-newkey rsa:2048 \
-nodes \
-keyout example.com.key \
-out example.com.key.com.csr

Submit to Namecheap​

Use cat to output the value of the csr.
Copy the content and paste it to the Namecheap SSL Vendor CSR step.

cat example.com.key.com.csr

Download SSL Bundle​

The SSL vendor will email you a SSL bundle which will used to create your SSL cert.

inermediate.crt​

Copy the content form example.com.ca-bundle and paste it into your server to a file called inermediate.crt using nano

nano intermediate.crt
key_com.crt​

Copy the content form example.com.crt and paste it into your server to a file called example.com.key_com.crt

nano example.com.key_com.crt
chained.crt​

Combine the content from both certs into one file by using cat and the redirect > commands

cat example.com.key_com.crt intermediate.crt > example.com.key.com.chained.crt

Nginx Default Config​

Run cat /etc/nginx/sites-enabled/default to see the config that will be edited.

Redirect HTTP:80 -> HTTPS:443​

server {
listen 80;
server_name 192.168.0.1 example.com;
rewrite ^/(.*) https://example.com/$1 permanent;
}

Listen HTTPS:443​

server {
listen 443 ssl;
server_name 192.168.0.1 example.com;

ssl_certificate /root/example.com.chained.crt;
ssl_certificate_key /root/example.com.key;
ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
ssl_ciphers 'EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH';
ssl_prefer_server_ciphers on;

root /var/www;
index index.html;

location / {}
}

Restart Nginx​

Verify your changes​
nginx -t
Restart Server​
service nginx restart
